Example of Digital Output Allocation
The table below shows an example of allocating input signals. Please note the set
values of 0x2210~0x2217.
DO#1
DO#2
DO#3
DO#4
DO#5
DO#6
DO#7
DO#8
ALARM
(CONTACT
B)
RDY
(CONTACT
A)
BRAKE
(CONTACT
B)
INPOS1
(CONTACT
A)
ORG
(CONTACT
A)
EOS
(CONTACT
A)
TGON
(CONTACT
A)
TLMT
(CONTACT
A)
CN1
Pin number
Set
Parameter
Bit
Set value
Content
15
7~0
DO # 1 (35,36)
0x2210
1
0x02
0x8002
ALARM (Contact B)
DO # 2 (37,38)
0x2211
0
0x03
0x0003
RDY (Contact A)
DO # 3 (39,40)
0x2212
1
0x01
0x8001
BRAKE (Contact B)
DO # 4 (41,42)
0x2213
0
0x05
0x0005
INPOS1 (Contact A)
DO # 5 (43,44)
0x2214
0
0x10
0x0010
ORG (Contact A)
DO # 6 (45,46)
0x2215
0
0x11
0x0011
EOS (Contact A)
DO # 7 (47,48)
0x2216
0
0x0A
0x000A
TGON (Contact A)
DO # 8 (49,50)
0x2217
0
0x06
0x0006
TLMT (Contact A)
Table 58. Example of Signal Output Allocation
4.5.3 Using User I/O
User I/O refers to a portion of I/S provided by the drive used for user‘s purposes
other than the purpose of controlling the drive. All contacts provided through I/O
connector can be used as User I/O.
If the number of User I/O required is small, you can use the drive‘s I/O connector
instead of using additional I/O modules, resulting in cost reduction.
This drive provides up to 16 input signals and 8 output signals as user I/O.
