5.3 Setup: Test Mode:
Test Mode provides the ability to test the inputs and outputs (I/O’s) of the FilterTec Plus outside
of the normal operational modes. Upon pressing Select, the FilterTec Plus will attempt Scale
Initialization. If it passes, the next Test appears. If it fails, press any key and the next Test
appears. Use the Star (*) button to move between tests.
Motor: This tests the motor. Use the Rate/Pressure button to change the motor speed. Use
the Run / Stop buttons, and the CW / CCW keys to exercise the motor. The encoder
pulses/second is displayed.
Keypad: This tests the keypad. Press the buttons in any order, and an appropriate number
is displayed. Left to right, top to bottom, they are numbered 1 through 0, the Star key
passes if it moves to the next test.
Scale: If a scale is connected and is communicating properly, the value here will match that
of the scale.
Pressure: If SciPres Disposable Pressure Sensors are connected, they will display the
measured pressure, P1, P2, P3. By pressing the A, B, or C keys, the sensors may be
zeroed. If there is no sensor connected,
--.- will be displayed.
Temperature: If a SciTemp Disposable Pressure Sensor is connected, the measured
temperature in ⁰C will be displayed. If no sensor is connected, 0.0 is displayed.
Valves: If Valve V or W is connected, press the A or B button to test them.
Analog: Displays the analog value for Channels 1, 2 and 3 based upon input and Hi/Lo
range settings.
TTL Switches: By using Left and 1/0 to change the BIT setting, the TTL outputs may be
tested. You must have a DMM connected to measure the voltage, it will be 0.0 if Switch is
set to 0, and 5.0 Vdc if set to 1. (display is 1234 if all are high, 0000 if all are low)
- SETUP – TEST MODE
UP DOWN SELECT
SCALE INTITIALIZATION
Please Wait
SELECT
STAR KEY
- TEST- 10% 00000
CW CCW
- TEST- KEYPAD
- TEST- SCALE
0.00 0.00 0.00
- TEST- PRESSURE
00.0 00.0 00.0
SCALE ERROR
Hit any key
- TEST- VALVES
V1 W1
- TEST- TEMPERATURE
0.0
STAR KEY
STAR KEYSTAR KEY
STAR KEY
- TEST- ANALOG
0.0 0.0 0.0
Sw – 1234 – BIT 1
LEFT 1/0 Select
STAR KEY
STAR KEY
