Parker SciLog FilterTec Plus User Manual

49
5.4 Setup: Ethernet
Ethernet allows setting of the IP Address, Subnet Mask and Gateway for the FilterTec Plus.
This allows communicating with the FilterTec Plus via Modbus TCP/IP when it becomes
available. Initially, if set properly for the company network, the user can ping the unit from a
command prompt. Consult the company Network Administrator for the proper settings. A
crossover cable can be used if connected directly to a PC, otherwise use a standard network
patch cable and a hub or switch.

IP Address: The default IP Address for the FilterTec Plus is 192.168.0.191. Use ADDR1
through ADDR4 to modify this address.

Subnet Mask: The default Subnet Mask is 255.255.255.0. Use MASK1 through Mask4 to
modify this address.

Gateway: The default Gateway is 192.168.0.1. Use GATE1 through GATE4 to modify this
address.
- SETUP - ETHERNET
UP DOWN SELECT
ETHERNET: ADDR1
UP DOWN SELECT
SELECT
ETHERNET ADDR1: 192
INCR DECR SELECT
ETHERNET: ADDR2
UP DOWN SELECT
ETHERNET ADDR1: 168
INCR DECR SELECT
ETHERNET: ADDR3
UP DOWN SELECT
ETHERNET ADDR1: 0
INCR DECR SELECT
ETHERNET: ADDR4
UP DOWN SELECT
ETHERNET ADDR1: 191
INCR DECR SELECT
ETHERNET: MASK1
UP DOWN SELECT
ETHERNET MASK1: 255
INCR DECR SELECT
ETHERNET: MASK2
UP DOWN SELECT
ETHERNET MASK2: 255
INCR DECR SELECT
ETHERNET: MASK3
UP DOWN SELECT
ETHERNET MASK3: 255
INCR DECR SELECT
ETHERNET: MASK4
UP DOWN SELECT
ETHERNET MASK4: 0
INCR DECR SELECT
ETHERNET: GATE1
UP DOWN SELECT
ETHERNET GATE1: 192
INCR DECR SELECT
ETHERNET: GATE2
UP DOWN SELECT
ETHERNET GATE2: 168
INCR DECR SELECT
ETHERNET: GATE3
UP DOWN SELECT
ETHERNET GATE3: 0
INCR DECR SELECT
ETHERNET: GATE4
UP DOWN SELECT
ETHERNET GATE4: 1
INCR DECR SELECT
UP
UP
UP
UP
UP
UP
UP
UP
UP
UP
UP
