8200w² Monitor Instruction Manual
2 Introduction
2.1 Manual Conventions
All dimensions stated in this manual are in millimetres unless otherwise indicated.
The manual has been written assuming the user has a basic knowledge of instrumentation and an
understanding of the type of measurements being made. Training in the use of the 8200w² Monitor and
sensors can be provided, please contact Partech for further information.
Icons have been used throughout this manual to draw your attention to precautions and useful notes.
They are categorised in the following way:
NOTES: Specifications and general notes of interest to the user.
GENERAL CAUTION: Used where caution is required to prevent injury, damage, corruption of
data, loss of calibration or invalidation of warranty etc.
INSTALLATION NOTES: General installation notes of interest to the installer.
ELECTRICAL CAUTION: Used where there is a danger of electric shock to the installer or end
user, or where caution is required to prevent damage to the instrument.
MAINTENANCE NOTES: Used to highlight recommended maintenance procedures and help with
fault finding.
ENVIRONMENTAL NOTES: General notes on environmental issues, waste and disposal.
2.2 WaterWatch² Trademark
WaterWatchw² is the family name for the w² range of monitors and sensors. Sensors and instruments
designed for specific use with the 7300w² & 8200w² Monitors will be suffixed with the w² trademark.
2.3 Scope of Manual
This manual describes the installation, configuration, testing and operation of the 8200w² Monitor. While
basic configuration of sensors is included in this manual, please refer to the specific user manual for each
sensor for a comprehensive configuration set-up.
2.4 Options
Part No. Description
229623
SludgeWatch 8200w² Fixed Sludge Level Detector (85 to 264VAC, 3 x Relay Outputs)
229624
SludgeWatch 8200w² Fixed Sludge Level Detector (9 to 36VDC, 3 x Relay Outputs)
2.4.1 Compatible Sensors
The 8200w² monitor can be used with the following Partech sensors:
Part No. Description
223893
SoliTechw² IR Sensor (Range: 0-200 mg/l, Cable Length: 10 metres)
223895
SoliTechw² IR Sensor (Range: 0-1,500 mg/l, Cable Length: 10 metres)
223897
SoliTechw² IR Sensor (Range: 0-10,000 mg/l, Cable Length: 10 metres)
223899
SoliTechw² IR Sensor (Range: 0-30,000 mg/l, Cable Length: 10 metres)
All the above sensors are available with 20 metre options. Contact Partech for details.
Page 6 of 34 229844IM Issue 01 Issue Date 24/06/2019
