5. SET-UP & ADJUSTMENTS
. ..B. ROLLER...
Adjustment
Checking Roller Clearance
It is recommended that the following
procedure be demonstrated to the
user. Once the proper roller clearance
is experienced, the use of a pull
scale and vise-grip pliers may not be
necessary.
1. Grip one support
+ a time
v i/
r
Excessive tension can
,rlse blade to warp.
4. Move vise-grip pliers to the
bottom support roller and check
in the same manner as the top
support roller.
Adjust roller
clearance so that clearance of
both rollers is the same.
Example:
Setting may vary between 4565N
(lo-14 Ibs.), but must be the
same within 4.5N (1 lb.) on both
upper
and lower
roller.
For
example, if the upper roller is
50N (11 Ibs.) the lower roller
must be 50N f 4.5N (11 + 1 lb.).
12
