Partner PT-5910 - Memory; Battery; LPT Port, PS;2 Port, DC 12 V connector and Audio Jacks

55
Memory
Before proceeding, remove the following
FRUs.
• “Front Cover” on page 60.
1. Open the clips.
2. Pull out the memory module.
Battery
Before proceeding, remove the following FRUs.
• “Front Cover” on page 60.
1. Open the hock.
2. Pull out the battery.
LPT Port, PS/2 Port, DC 12V connector and Audio Jacks
Before proceeding, remove the
following FRUs.
• “Front Cover” on page 60.
1. Remove all screws from the
LPT port, PS/2 port, DC
12V connector and the audio
jacks.
2. Remove the LPT port, PS/2
port, DC 12V connector and
the audio jacks.
