11.2 Set up the network
Automatically: To set up the IP address automatically, the option DHCP is selected. Afterwards,
the Internet module retrieves all settings from the DHCP server.
Manually: Via the menu items IP address, Net mask, Gateway address and DNS address it is
possible to manually enter the network settings. For information about the values to be entered
there, please contact your network administrator.
11.3 Information
In this menu item, the current network settings of the Internet module are displayed. In addition,
the firmware version and the MAC address can be seen.
12 Modbus settings*
The domestic hot water module can be connected to the Building Management System (BMS)
via the Modbus interface of the FC3.10 controller. In this menu item, the Modbus transfer
parameters such as Baudrate, data bits, stop bits, parity etc. can be set. Detailed information for
the setting can be found in chapter 23 "Connection to Building Management System".
*Settings only visible with installer code (see chapter "User code").
13 USB
The controller has a service interface (USB port) for standard USB flash drives. To connect a
USB flash drive, first remove the EPP insulation around the controller. In a second step,
unscrew the screw in the lower area of the controller and remove the white front panel.
The USB port is at the right of the display at the side of the controller.
ATTENTION
Danger of damage and malfunction!
Subsequent damage by using USB 3.x is possible.
 Only use USB flash drives of the type 1.x or 2.x for this service interface.
