Pearpoint Flexitrax P550c - Page 144

P550c Operation Manual
6 Operating the system
www.pearpoint.com | 144
Poles
Connect as many poles as required ensuring that the push button is fully engaged.
Fig. 6.8 Poles assembly
Using the deployment tool
Once ready you can use the deployment tool, you can hook the strap or engage the cradle to the large
elevator bracket as shown below to lift the crawler assembly.
Push button
