P550c Operation Manual
6 Operating the system
www.pearpoint.com | 143
4 Secure the bracket to the elevator assembly using the new 4 off M6x12 screws supplied with the
lifting tool, and tighten firmly (recommended torque 8Nm or 70 In-Lbs).
Fig. 6.7 Elevator bracket assembly
O-ring
Bush
M6 x 16
Linkage arm
Linkage arm
1. Existing assembly
2. New assembly
