P550c Operation Manual
6 Operating the system
www.pearpoint.com | 185
5 Position and edit each item. While video recording is paused:
a. Press the Select item button repeatedly until the item you want is highlighted in red.
Note: If you have set the overlay text color to red, then the selected item is yellow.
b. Use the arrow keys on the keyboard to position the item on the screen.
c. Shapes and graphics: Press the Enlarge or Shrink buttons to resize the item.
d. Text: Press Enter on the keyboard to edit the caption. Press Enter again to save the changes.
If you need to remove an item, press the Delete button.
6 Enable the overlay. Press the Enable overlay button.
Do not omit this step. You must enable overlays to make them visible in your video recording!
They will stay visible until you disable overlays in step 8.
7 Resume recording for several seconds but do not move the camera!
For example, to display the overlays for 10 seconds, resume recording for 10 seconds. The overlay
items will remain visible during this segment of the video. You could also record an audio
commentary over this segment, for example, to explain the highlighted pipe defect.
8 Disable the overlay. Press the Disable overlay button to remove the overlay items from the next
video segment. (You do not need to pause the recording to do this.).
9 Continue the pipe survey.
If you detect further pipe defects that you want to highlight, repeat steps 2 through 8.
