REPAIR PARTS
Table 13.1: Heat Exchanger
Description
Quantity
Required
Stock
Code
1
Heat Exchanger – PF-850 1 5651
Heat Exchanger – PF-1000 1 5652
2 Burner Mounting Plate 2 54430
3 Flame Sensor Electrode w/Gaskets 2 54432
4 Ignition Electrode w/Gaskets 2 54431
5 Burner Element 2 54433
6 Flapper Assembly 2 54434
7
Supply/Return Sensor – 1/8" NPT 12 KW
4 54438
8 High Limit Switch – 1/4" NPT 2 54419
9
Header Supply Sensor – 1/4" NPT 12 KW
1 54418
10 Hex. Flange Nut M6 Fine Thread 12 –
11 Screw M5-0.80 x 16 mm Zinc Plated 10 –
12 Burner Gasket 2 54467
13 Screw M4 x 8 mm Zinc Plated 4 –
14 Flue Temperature Sensor 1 54111
15 Thermal Fuse 2 54466
