ECP300 EXPERT
Pag. 12
USE AND MAINTENANCE MANUAL
STANDARD ASSEMBLY KIT
For the purposes of assembly and use, the electronic ECP300 EXPERT control unit comes
with:
• N° 4 seals, to be fitted between the fixing screws and the box back panel
• N° 1 use and maintenance manual.
• N° 1 electrical drawing.
• N° 1 drilling layout.
• N° 2 probes NTC 10K 1%
MECHANICAL ASSEMBLY
Each panel is conceived to be wall-mounted; please choose depending on the
weight a correct fixing method.
Install the device in places where the protection rating is observed.
To effect correct electrical connection and maintain the protection rating, use
appropriate cable glands and plugs to ensure a good seal
Install the device at height allowing the installer an easier use and maintenance.
The installer must not be in danger when it’s working on the panel. Height must
be between 0,6 and 1,7 mt from the ground.
Install the device away from fire and heat sources and possibly repaired from
weather shelter.
Below we show step by step how to correctly install the panel.
CHAP. 3 - Installation
