ECP300 EXPERT
Pag. 27
USE AND MAINTENANCE MANUAL
Rev. 01-12
LIST OF LEVEL 1 VARIABLES (User Level)
VARIABLES MEANING VALUE DEFAULT
r0
Temperature difference compared to main SETPOINT
0.2 - 10 °C 2°C
d0
Defrost interval (hours)
0 - 24 hours 4 hours
d2
End
-
of
-
defrost setpoint
.
Defrost is not executed if the temperature read by the
defrost sensor is greater than d2
(If the sensor is faulty defrosting is timed)
-35 - 45 °C 15°C
d3
Max defrost duration
(minutes)
1 - 60 min 25 min
d7
Drip durat
ion
(minutes)
At the end of defrost the compressor and fans remain at
standstill for time d7, the defrost LED on the front panel
flashes.
0 - 10 min 0 min
F5
Fan pause
after defrost (minutes)
Allows fans to be kept at standstill for a time F5 after
dripping. This time begins at the end of dripping. If no
dripping has been set the fan pause starts directly at the end
of defrost.
0 - 10 min 0 min
A1
Minimum temperature alarm
Allows user to define a minimum temperature for the room
being refrigerated. Below value A1 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
- -45°C
A2
Maximum temperature alarm
Allows user to define a maximum temperature for the room
being refrigerated. Above value A2 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
- +45°C
tEu
Evaporator sensor temperature display
Displays
evaporator
temperature
(displays nothing
if dE =1)
read only
CHAP. 5 - Data programming
5.8
