Table 3: System 450 sensor types, setup values, and sensor or transducer product codes
Sensor type Unit of measurement value (condition/
units)
Effective sensing
range
1
Range of usable
values
1
Resolution
increment value
Minimum
proportional or
control band
2
Sensor product type number
2
P 50 bAR (Pressure/bar) 0 to 50 0 to 50 0.2 0.4 P499RCP-405C
P598RCPSN405C
P 100 PSI (Pressure/psi) 0 to 100 0 to 100 0.5 1 P499RAP-101C
P499RAP-101K
P499RCP-101C
P499RCP-101K
P598RAPSN101C
P598RAPSN101K
P598RCPSN101C
P598RCPSN101K
3
P 110
3
Hg/PSI (Pressure/Hg-psi) -10 to 100 -10 to 100 0.5 1 P499RAPS-100C
P499RAPS-100K
P499RCPS-100C
P499RCPS-100K
P598RAPSN100C
P598RAPSN100K
P598RCPSN100C
P598RCPSN100K
P 200 PSI (Pressure/psi) 0 to 200 0 to 200 1 1 P499RAP-102C
P499RAPS102C
P499RAPS102K
P499RCPS102C
P499RCPS102K
P598RAPSN102C
P598RAPSN102K
P598RCPSN102C
P598RCPSN102K
P 500 PSI (Pressure/psi) 0 to 500 90 to 500 1 5 P499RAP-105C
P499RAP-105K
P499RCP-105C
P499RCP-105K
P598RAPSN105C
P598RAPSN105K
P598RCPSN105C
P598RCPSN105K
P 750 PSI (Pressure/psi) 0 to 750 150 to 750 2 6 P499RAP-107C
P499RAP-107K
P499RCP-107C
P499RCP-107K
P598RAPSN107C
P598RAPSN107K
P598RCPSN107C
P598RCPSN107K
HI°F °F (Temperature/degrees) -50 to 360
4
-40 to 350
4
1 1 TE-631x
TE-6000-x
TE-68NT-0N00S
HI°C °C (Temperature/degrees) -45.5 to 182
-40 to 176
4
0.5 0.5 TE-631x-x
TE-6000-x
TE-68NT-0N00S
bin
5
Open or Closed
5
N/A N/A N/A N/A N/A
1 Because of the way that the System 450 Differential Sensor (Sn-d) is set up and calculated with two identical sensors (Sn-1 and
Sn-2), the Range of Usable Values is twice as large as a single sensor. See Table 5 for the Range of Usable Values when an output
references Sn-d.
2 Refer to the System 450 Series Modular Controls Product Bulletin (LIT-12011458), System 450 Series Modular Controls Catalog Page
(LIT-1900549), or the System 450 Series Controls Systems with Communications Technical Bulletin (LIT-12011826) for additional ordering
information for System 450 compatible sensors and transducers.
3 See Setting up Outputs that reference a P 110 Sensor for information on setting up System 450 outputs that reference the P 110
Sensor Type.
4 Many of the temperature sensors that can be set up as HI°F or HI°C Sensor Types are not designed for use across the entire range
of usable values for HI°F and HI°C Sensor Types. Refer to the Technical Specifications for the sensor you intend to use to determine
the ambient temperature range that the sensor is specified to operate in. The TE-6000-6 Nickel Sensor is the only sensor designed
for use over the entire temperature range.
5 Selecting the bin Sensor Type for a sensor (Sn-1, Sn-2, or Sn-3) sets up the input to control relay outputs (only) based on the state
of the binary input contacts (open or closed) connected to the sensor input (Sn1, Sn2, or Sn3). See Binary Input control for Relay
Outputs for more information.
Figure 62 provides a System 450 UI setup example.
System 450 Series Control Module with Ethernet Communications Installation Guide8
