TAURUS™ VS Variable Speed Pump Installation and User’s Guide
OPERATING THE PUMP
Setting the Clock
When the pump is first plugged in, the clock will
blink to indicate that is has not been set. Any daily
schedule set by the user will be based on this clock
setting, so it will be necessary to set the clock first.
To Set the Clock:
1. Press and hold the Display button for 3 seconds.
2. Use the “+” and “-” arrows to choose between a
12 or 24 hour time format.
3. Press Display to advance in the Clock Setup
menu
4. Use the “+” and “-” arrows to change the time to
the correct time of day. In the 12 hour time format
AM/PM will display in the bottom right corner.
5. Press Display to advance.
6. Use the “+” and “-” arrows to adjust the screen
backlight brightness.
7. Press Display to exit the Clock Setup menu. The
clock is now set.
During a power outage, the drive will retain the clock
setting in memory for as long as 24 hours. If the
power is out longer than 24 hours the clock will have
to be set again. If the drive has lost the user set time,
the clock will continuously blink until the time is reset.
Once the time is reset the clock will stop blinking.
Note: When power is returned to the pump after
a prolonged outage (24+ hours) the clock will
automatically set itself to the Speed 1 start time, blink
and advance. The pump will also run the associated
schedule from that start time.
Using the Default Schedule
The default schedule is designed to provide enough
daily turnover to service a typical body of water. See
Table 2 for default schedule.
Duration
(Hours)
Speed
(RPM)
SPEED 1 2 3000
SPEED 2 10 1400
SPEED 3 2 2200
Table 2: Default Schedule.
SPEED 1 is set to begin at 8:00am and run at 3000
RPM for a duration of 2 hours. When SPEED 1 is
complete the pump immediately begins running the
default SPEED 2. SPEED 2 is factory default to 1400
RPM and will last for 10 hours. When SPEED 2 has
completed its run the pump will run SPEED 3 at 2200
RPM for a duration of two hours.
After 14 hours of run time and completing its run of
SPEED 3, the pump will enter a stationary/paused
state for the next 10 hours. The pump will restart at
8:00am the next morning and cycle through the default
schedule again. The pump will continue to run in this
in this manner until a custom schedule is programmed
into the drive by the user.
Note: The Start/Stop button must be pressed, and the
LED lit, for the pump to run.
