TAURUS™ VS Variable Speed Pump Installation and User’s Guide
Taurus™ VS Variable Speed Pump Replacement Parts List
15
14
13
12
11
24
8
9
10
76
20
53
22
18 1719
2
1
21
25 23
26
16
4
Item No. Part No. Descripon Item No.
14
1353128DRIVE ASSEMBLY15
2353135S MOTOR16
173355612SSSEALPLATE
184355619SEALPLATE GASKET
195355074IMPELLER
206355618DIFFUSER
217355030DIFFUSER SEAL
228351094BASE
239357161DRAIN PLUG
2410 192115 O-RING, DRAIN PLUG
2511 351089 VOLUTE
2612 357255 O-RING, LID #2-357
*13 355667 BASKET
Part No. Descripon
350091 LID, SEE THROUGH
351090 CLAMP, CAM AND RAMP
353110 VOLUTE ASSEMBLY (INCLUDES ITEMS 9-15)
072184 WASHER 3/8 IN. SS, 8 REQ.
355621 SCREW 3/8-16 X 2 1/4 HEX HEAD, 4 REQ.
355334 SCREW #8-32 HEX WASHER HEAD, 3 REQ.
355389 SCREW, IMPELLER LOCKING
354545SSEAL SET
354290 HEX HEAD SCREW 3/8-16, 4 REQ.
270141 NUT, 2 REQ.
350093 ADAPTER, 2 REQ.
6020018O-RING ADAPTER #2-226, 2 REQ.
351157 UNION KIT (CONTAINS 2X ITEMS 23-25)
353129Z KIT DIGITAL INPUT 25'
