9
TAURUS™ VS Variable Speed Pump Installation and User’s Guide
Operating the Pump While Running
Pressing the Display button will cycle through the
current parameters.
• Speed — current run speed
• Time — current time of day
• Duration — amount of time remaining at the
current run speed
• Watts — amount of watts currently being
consumed
Pressing any of the Speed Buttons (“1”, “2”, “3”,
“Quick Clean”) while the pump is running will act as a
temporary override. It will run the speed and duration
that is programmed for that button. Once completed
it will default back to the appropriate point in the
programmed schedule.
Note: If you adjust the speeds of the schedule while
the pump is running, it will run the adjusted speed
for the rest of the current duration, but will not save
the adjustments. Exception: Speed and Duration
adjustments to QUICK CLEAN will always be
immediately saved.
Quick Clean
When running Quick Clean, pressing the “+” or “-” arrows
will change the speed accordingly. Pressing the Quick
Clean button again within 10 seconds of pressing the “+”
or “-” arrows will allow you to adjust the duration of Quick
Clean via the “+” and “-” arrows. These changes will be
saved immediately and will become the new defaults for
Quick Clean. Pressing the Quick Clean button again will
cycle through the two Quick Clean settings. The pump
will exit editing mode if no additional buttons are pressed
within 10 seconds.
When Quick Clean is running and you wish to stop
the Quick Clean prior to the duration being completed,
press and hold the Quick Clean button for 3 seconds
and the pump will return to the appropriate point in the
programmed schedule.
Speed Priorities (Non-External Control)
For schedule duration settings, SPEEDs are prioritized
in numerical order: SPEED 1 -> SPEED 2 -> SPEED
3. SPEED 1 is the highest priority, while SPEED 3 is
the lowest.
The drive will not allow a user to program a schedule
of more than 24 hours. When the 24th hour of duration
is programmed it will take time from the lower priority
speeds in order to add them to the SPEED currently
being adjusted.
Example:
Starting Schedule (Before Adjustment)
SPEED 1 duration = 20 hours
SPEED 2 duration = 2 hours
SPEED 3 duration = 2 hours
If the user reprograms SPEED 1 to run for 23 hours,
SPEED 2 (lower priority speed) will automatically
adjust to a 1 hour duration and SPEED 3 (lowest
priority speed) will adjust to a 0 hour duration.
End Schedule (After Adjustment)
SPEED 1 duration = 23 hours
SPEED 2 duration = 1 hour
SPEED 3 duration = 0 hours
Note: If a user wants to have a period of time
during the day when the pump is not running, any
of the SPEEDs can be programmed to 0 RPM. This
will cause the pump to remain stationary/paused
throughout the duration of that SPEED.
If power is connected to the pump motor,
pressing any of the following buttons referred to
in this section could result in the motor starting. Failure to recognize
this could result in personal injury or damage to equipment.
