158
5
Function Reference
You can combine two or more AF360FGZ external flashes or you can use
two or more AF360FGZ external flashes in combination with the built-in
flash. Connect them as shown in the figure below: Attach an off-camera
shoe adapter F (optional) to the external flash and the hot shoe adapter F
(optional) and connect the extension cord F5P (optional) to the off-camera
shoe adapter F on the other external flash.
When combining two or more external flashes
Discharging Multiple Flashes
• Do not combine with accessories that have a different number of contacts
such as a Hot Shoe Grip. A malfunction may occur.
• Combining with flashes from other manufacturers may cause equipment
breakdown. We recommend using the AF360FGZ.
When using multiple AF360FGZ units or an AF360FGZ unit with the built-in
flash, P-TTL is used for flash control.
