39
2
Getting Started
Adjusting the Viewfinder Diopter
Adjust the viewfinder to suit your eyesight.
If it is difficult to see the viewfinder image clearly, slide the diopter
adjustment lever sideways.
You can slide the diopter from –2.5m
-1
to +1.5m
-1
.
1
Look through the viewfinder
and point the camera at a well-
lit scene. Slide the diopter
adjustment lever left or right.
Adjust the lever until the AF frame in
the viewfinder is focused.
Eyecup is attached to the viewfinder portion
when camera leaves the factory. Diopter
adjustment is available with the eyecup
attached. However, adjustment is easier
with the eyecup removed as shown above.
To remove the eyecup, pull one side of the
Eyecup FN out and toward you as shown on
the right.
AF Frame
To Next Page
