11.3 VPN Status
VPN Status is shown in the Dashboard. The connection status of each connection profile is shown as
below.
VPN connection status is also shown on the LCD panel of Peplink Balance 380, 390, 580, 710 and 1350.
By clicking the Details button at the top-right hand corner of Site-to-Site VPN table, you will be forwarded
to Status > Site-to-Site VPN. You can view the subnet and WAN connection information of each VPN
peer. Please refer to section 19.5 for details.
IP subnets must be unique among VPN peers
The entire inter-connected Site-to-Site VPN network is one single non-NAT IP network. No two subnets in two sites
shall be duplicated. Otherwise, connectivity problems will be experienced in accessing those subnets.
