https://www.peplink.com
25
Copyright @ 2021 Pepwave
Cellular 2*
Blinking slowly Connecting to network(s)
Green Connected to network(s)
* For MAX-TST_DUO
LAN and Ethernet WAN Ports
Green LED
ON 1000 Mbps
OFF
10 Mbps / 100 Mbps or port is not connected
Orange LED
ON Port is connected without traffic
Blinking Data is transferring
OFF Port is not connected
Port Type Auto MDI/MDI-X ports
2.8 MAX Transit Mini
2.8.1 Panel Appearance
2.8.2 LED indicators
The statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF
System initializing
Red
Booting up or busy
Blinking red Boot up error
Green Ready
