2.23.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
LAN and Ethernet WAN Ports
Green LED
ON 1000 Mbps
OFF 10 Mbps / 100 Mbps or port is not connected
Orange LED
ON
Port is connected without traffic
Blinking Data is transferring
OFF No data is being transferred or port is not connected
Port Type Auto MDI/MDI-X ports
2.24 MAX BR1 IP55
2.24.1 Panel Appearance
