Basic Installation
27
System Configuration
Figure 5 Components of the System
You can place the (optional) printer to either side of the spectrometer to suit
your own preferences.
Do not place the printer or other instruments on top of the spectrometer.
When placing instruments side by side, always leave a small gap between
them.
If you wish, you can set up the printer on a separate trolley (cart).
Make certain that air can circulate freely over and under the system as well as
behind it.
CAUTION
Do not place anything on or under any of the components that could
hinder free air circulation.
Spectrometer
External Printer
(option)
