Maintenance
65
Changing Fuses
WARNING
Electrical hazard
To prevent potential injury to yourself and damage to the instrument,
switch OFF all instruments in the system and disconnect them from the
line power supply before you alter, or make any new, electrical
connections.
The fuses are located in a fuse holder at the rear of the instrument:
Figure 15 Rear view, Fuse Holder
1. Switch off the instrument and remove the line power cord from the electrical
supply.
2. Squeeze the two lugs at each side of the fuse holder and gently pull out.
Fuse Holder
Fuse Holder
