Accessory Installation
39
Accessory Installation
General
To operate the spectrometer with some accessories, for example the Peltier
Temperature sensor, you need an accessory printed circuit board (PCB) and a
connector panel. They will be installed by PerkinElmer service.
Procedures for installing the accessories in the spectrometer are described in the
directions provided with the respective accessory.
To install certain accessories you need to remove the sample compartment cover.
The required procedures are described below.
In the directions provided with some sample handling accessories, reference is made
to earlier models in the Lambda Series of spectrometers. These directions are
generally applicable to the current series of instruments since the sample
compartment is standardized.
Accessory Connector Panel (LP5/5)
To facilitate manufacturing procedures, a common connector panel is used for the
Lambda Series of instruments. Not all connectors are required for Lambda 20, or
Lambda 40 (see table below).
