Lambda 20, Lambda 40 UV/Vis Spectrometers
66
3. Replace the spent fuse with a new one of the same type and rating:
Voltage Standard
100 V – 120 V 6.3 A slow-blow
210 V – 240 V 3.15 A slow-blow
NOTE: The module has two fuses.
4. Replace the fuse holder.
Align the lug at the bottom of the fuse holder with the slot in the socket. A
click is heard as each lug snaps into place.
NOTE: If you use the correct fuses but the instrument still does not work correctly, or the
fuses blow repeatedly, contact your PerkinElmer office or representative.
Maintaining the Internal Printer
The internal printer needs no special maintenance. You only need to:
Change the printer paper
Change the printer ribbon
when necessary.
Changing the Printer Paper
1. Lift off and remove the old paper roll.
2. Replace with a new paper roll.
3. Cut square the end of the paper.
4. Carefully feed the end of the paper into the slot at the top of the printer.
