Lambda 20, Lambda 40 UV/Vis Spectrometers
40
Designation Connector for Remarks
Accessory Port
Linear transporter,
multi-sipper
I
2
C-bus interface
Serial Port
PC, (printer) First RS 232 C interface
Parallel Port
Printer Centronics interface
J6, Autosampler
AS90/91 autosampler
J14, Cell Changer, Sipper
Older accessories Active
P15, 2
nd
RS 232
PC, printer Second RS 232 C
interface
J10, J11, Temp
Temperature sensor J10: 2-pin socket
J11: 4-pin socket
J30, Peltier
Peltier cell changer
and Peltier cell holder
Active
Temp
P15
A
utosam
p
ler J6
Cell Changer
Sipper
2
n
d
RS232
Peltier J30
Sphere J8
Parallel Port Serial Port Accessory Port
J14
J10
J11
J1
