Lambda 20, Lambda 40 UV/Vis Spectrometers
30
Inscription legible
on Holder
Use in Spectrometer
LAMBDA
In this position, the cell holder can be used with all
Lambda Series Spectrometers.
BIO LAMBDA 2
In this position, the cell holder can be used with Lambda
2 Series Spectrometers as Lambda 10, 20, 40, Bio, etc.
(baseplate with 4 threaded holes).
The smallest beam diameter is exactly in the middle of
the cell. This is useful especially for operation with
micro and semi-micro cells.
Installing the Cell Holder
Install the single cell holder in the sample compartment as follows:
1. Orientate the holder so that the lifter is toward the rear of the sample
compartment.
2. Lower the holder so that the two alignment holes slip onto the two studs on the
baseplate at the bottom of the sample compartment.
The arrow on the cell holder must line up with the centre point of the baseplate,
and
BIO LAMBDA 2 must be legible.
BIO
LAMBDA 2
Arrow
Center Point
Tube Ports
