Glossary
87
case frame assembly lower part of the instrument case, not
replaceable and fitted with external connector
and ventilator
control panel plate equipped with three LED-fitted press
buttons that are used to control the
instrument's operation
control unit device through which the instrument's
operation is managed
cover plate lid of the top measuring head body covering
the filter slides in their light-tight channel. It
contains all lenses placed above the filter
slides and supports the light sources, and
detectors.
detector PMT that intensifies and measures the signal
from the emission channel
Note! The detector has a normal side window
PMT used for both photon calculation and
analogue mode.
dichroic mirror beamsplitter that permeates/reflects light of a
certain wavelength range
mirror used to selectively transmit light
according to its wavelength
diffraction grating a device for dispersing light, used as the basis
for a monochromator
dispenser unit device for dispensing to a microtitration plate
in EnVision
one or two pumps can be installed. A tip
mount is used to position the tip(s)
dual mirror module assembly to guide excitation light onto the
sample and emission light to the detector
which also divides emission light between the
detector and the 2nd detector
emission cable optical cable that guides emission light from
the bottom measuring head to the emission
light selector
emission light mirror
holder
part that guides the emission light from top of
the sample into the 2nd detector module in
models without the bottom measuring option
