PerkinElmer Lambda 365 User Manual

Lambda 365 Installation . 33
Environmental Requirements
This system is for indoor use only.
Requirement Description
Indoor use Altitude up to 2000 m (6,500 ft.)
Pollution degree 2
Dimensions
491 mm (W) × 538 mm (D) × 258 mm (H)
[19.3 in. (W) 21.1 in. (D) 10.1 in. (H)]
Weight 23.5 kg (52 lbs)
Electrical supply AC 100-240V, 50/60Hz, 110W
Operating Temperature
15 - 35℃ (59 - 95°F)
Operating humidity Less than 80% relative, non-condensing
Mains Supply Voltage
Functions
± 10%
Computer Requirements
Requirement Description
Hardware Processor : Intel® Core 1.5 GHz or faster
RAM : At least 1GB
Hard disk : 50GB with 1GB free
Input devices : Mouse and keyboard
Monitor : 1024x768 (minimum)
Media : CD ROM Drive
Port : USB port for the data acquisition
Operating System
Microsoft
®
Windows 7
Output device
Microsoft
®
Windows compatible printer

PerkinElmer Lambda 365 Specifications

General

Wavelength Range	190 - 1100 nm
Power Requirements	100-240 V AC, 50/60 Hz
Wavelength Accuracy	±0.3 nm
Wavelength Repeatability	±0.1 nm
Wavelength Reproducibility	±0.1 nm
Photometric Repeatability	±0.001 Abs
Baseline Flatness	±0.0005 Abs
Baseline Stability	<0.0003 Abs/hour (after warm-up)
Data Interval	0.1 - 5 nm
Light Source	Tungsten halogen lamp and deuterium lamp
Sample Compartment	Standard 10 mm cell holder
Detector	Silicon Photodiode
