PerkinElmer Lambda Series User Manual

26 . High-Performance Lambda Spectrometers Getting Started Guide
Overview
The Lambda 650, 750, 850, 950 and 1050 spectrometers are versatile instruments operating
in the ultraviolet and visible (UV/Vis) spectral ranges. Additionally, the Lambda 750, 950, and
1050 spectrometers operate in the near-infrared (NIR) region. The spectrometer features a
double-beam, double-monochromator, ratio-recording optical system.
Figure 7 Main features of the high-performance Lambda spectrometer
Lamp compartment
Power switch
Connector panel
Sample
compartment
Detector compartment or
accessory
Purge inlets

PerkinElmer Lambda Series Specifications

General

Category	UV Vis Spectrophotometer
Spectral Bandwidth	0.5, 1, 2, 4 nm
Data Interval	1, 2, 5 nm
Slit Width	0.5, 1, 2, 4 nm (selectable)
Light Source	Deuterium and Tungsten Halogen lamps
Display	LCD
Interface	USB, RS-232
Power Requirements	100 - 240 VAC, 50/60 Hz
Wavelength Range	190-1100 nm
