PerkinElmer Lambda Series User Manual

Installing your Lambda Spectrometer . 31
Unpacking
CAUTION
Take great care when installing your Lambda spectrometer, and follow
the procedures described in this manual. If you require assistance,
contact your local PerkinElmer Service Engineer.
WARNING
The instrument weighs about 77 kg. Four people are needed to lift the
instrument.
1. Unpack the components carefully, using four people to lift the instrument itself.
Keep the packing materials for possible future storage or reshipment.
Figure 10 Lifting the instrument
Position of hands
under instrument

PerkinElmer Lambda Series Specifications

General

Category	UV Vis Spectrophotometer
Spectral Bandwidth	0.5, 1, 2, 4 nm
Data Interval	1, 2, 5 nm
Slit Width	0.5, 1, 2, 4 nm (selectable)
Light Source	Deuterium and Tungsten Halogen lamps
Display	LCD
Interface	USB, RS-232
Power Requirements	100 - 240 VAC, 50/60 Hz
Wavelength Range	190-1100 nm
