PerkinElmer Lambda Series User Manual

24 . High-Performance Lambda Spectrometers Getting Started Guide
Moving the Instrument
WARNING
The instrument weighs about 77 kg. Four people are needed to lift the
instrument.
CAUTION
If you must move the instrument any great distance, especially if the
instrument may be subject to vibrations or jolts, contact your local
PerkinElmer Service Engineer for guidance or advice.
If you are only moving the instrument within the laboratory or to a nearby laboratory then
four people should lift the instrument using the handholds, as shown in Figure 6.
Figure 6 Position of handholds for lifting the instrument

PerkinElmer Lambda Series Specifications

General

Category	UV Vis Spectrophotometer
Spectral Bandwidth	0.5, 1, 2, 4 nm
Data Interval	1, 2, 5 nm
Slit Width	0.5, 1, 2, 4 nm (selectable)
Light Source	Deuterium and Tungsten Halogen lamps
Display	LCD
Interface	USB, RS-232
Power Requirements	100 - 240 VAC, 50/60 Hz
Wavelength Range	190-1100 nm
