Perkins 1204F-E44TA - DEF Connection Detail

1204F - DEF System Supplement
5.2.2 DEF Connection Detail
The following DEF lines are required to be installed by the customer
These DEF lines should be selected from the option offering.
• A DEF suction line from the tank header to the pump - Fig 5.3
• A DEF pressure line from the pump back to the injector - Fig 5.4
• A DEF return line from the injector to the tank header - Fig 5.5
The individual connection points for each connection are detailed below. Failure to meet minimum
line length values can lead to pump instability as well as thermal stress to the heater filament
Table 5.3- DEF Line Connections
Line
Line Start Line End
Recommended
point for line
heater
connection
Line lengths
#
SAE
J2044
Size
Connection
point
#
SAE
J2044
Size
Connection
point
Min
(mm)
Max
(mm)
DEF Suction
Line
I
9.53mm
(3/8”)
DEF tank
header outlet
J
9.53mm
(3/8”)
PEU Inlet PEU Inlet 1000 2000
DEF Pressure
Line
K
7.94mm
(5/16”)
PEU Outlet L
7.94mm
(5/16”)
Injector Inlet PEU Outlet 1500 4000
DEF Return
Line
M
9.53mm
(3/8”)
Injector Outlet N
7.94mm
(5/16”)
DEF tank
header inlet
DEF tank Inlet 1500 4500
NOTE: PERKINS LINES ARE SUPPLIED PRE-FITTED WITH APPROPRIATE SAEJ2044 CONNECTORS, SEE FIG 5.2
Refer to section 2.11 for maximum total line length of the system
A&I manual Publication TPD 1832 – Production issue 3. Page 31 of 41
