Top Service
Illustration 78 g03090965
1. Ensure that dirt cannot enter the breather
assembly. Ensure that the outside body of the
breather assembly is clean and free from damage.
Place a container under the breather assembly.
2. Rotate the top cap (1) counterclockwise into the
unlocked position. Remove the top cap from the
body of the breather (3) and remove the filter
element (2).
Illustration 79 g03090963
3. Remove the old seal (4) and install a new seal.
Note: The cut away from section (5) in the top cap
allows access to the seal.
Illustration 80 g03090938
(A) Alignment position
(B) Alignment position
SEBU8732 107
Maintenance Recommendations
Engine Crankcase Breather Element - Replace
