Illustration 31 g03051677
Typical example
(2) Lifting eyes for the CEM
Refer to illustration 31 for the location of the lifting
eyes in order to lift the CEM. The lifting eyes (2) are
designed only to lift the CEM. The lifting eyes (2)
must not be used to lift any other parts of the
application.
Note: If the CEM is removed from the application, the
inlet and outlet connections must be protected in
order to prevent damage.
Pump Electronics Tank Unit (PETU) Only
The tank on the PETU should be empty before the
assembly is lifted.
Illustration 32 g03419909
Typical example
(3) Lifting eyes for PETU
Refer to illustration 32 for the location of the lifting
eyes in order to lift the PETU.
SEBU8732 33
Lifting and Storage
Product Lifting
