DIESEL ENGINE DATA
4006/8 Diesel, May 1998 9
EXHAUST SYSTEM
FLYWHEEL
FLYWHEEL HOUSING
CRANKSHAFT
NOTE: Subject to a torsional vibration investigation different T.V. dampers may be fitted
4006 4008
Manifold type Dry Dry
Exhaust outlet flange (non uprate) Vertical (single) Vertical (single) Option
(uprate) Vertical (single) Option
Vertical (twin)
Vertical (twin)
Mating flange (non uprate) 1 x 8" Table "D" BS4 1 x 10" Table "D"
(uprate)
1 x 10" Table "D"
2 x 6" Table "D" Option
2 x 6" Table "D"
Max. exhaust back pressure See Product Information Manual
Max. exhaust temperature See Product Information Manual
SAE size 14" 18"
SAE size 0 0
Max. overhung weight on rear bearing 1000 kg
Tuning plate 1 x 14.6" -
T.V. damper (non uprate) 1 x 14" 2 x 20"
(uprate) 1 x 18"
