13
100 Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green
400 Series
Starter ring gear
To remove and to fit Operation 13-4
If the ring gear is excessively worn, renew.
When the wear is not excessive remove the ring gear and fit 90° from the original position.
To fit the ring gear heat to 120 °C to 150 °C (248 °F to 301°F).
Caution: Heat evenly, do not locally overheat.
H1109
