8 Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green
400 Series
Engine lift equipment
Recommended torque: lifting eye bolts
Maximum engine weights
(1) Engine may alter with final specification.
Engine Nm (lbf ft) kgf m
All models 26 (19) 2,6
Engine Engine specification Maximum engine
weights (dry)
(1)
403C-11
Long flywheel housing specification 114 kg
Short flywheel housing specification 96 kg
Backplate specification 87 kg
403C-15
Long flywheel housing specification 176 kg
Short flywheel housing specification 154 kg
Backplate specification 150 kg
404C-22
Long flywheel housing specification 220 kg
Short flywheel housing specification 196 kg
Backplate specification 184 kg
404C-22T
Long flywheel housing specification 230 kg
Short flywheel housing specification 206 kg
Backplate specification 194 kg
H1032
