Perkins 404C-22T Workshop Manual

2
Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 11
400 Series
Special torques
Torque Nm (lbf ft) kgf m
Angleich 5 (3.6) 0,5
Atomiser 64 (47.2) 6,4
Atomiser pipes 23 (16.9) 2,3
Blanking plug rear of cylinder block 7 (5.1) 0,7
Crankshaft carrier to block 27 (19.9) 2,7
Connecting rod nuts 52 (38.3) 5,2
Crankshaft nut 303 (223.5) 30,3
Crankshaft sub assembly 52 (38.3) 5,2
Exhaust manifold 25 (18.4) 2,5
Flywheel 74 (54.5) 7,4
Fuel injection pump 15 (11) 1,5
Fuel injection pump leak off rail 7 (5.1) 0,7
Glow plug 18 (13.2) 1,8
Head setscrew 101 (74.5) 10,3
Leak off rail 27 (19.9) 2,7
Lift pump banjo 12 (8.8) 1,2
Lift pump mounting setscrew 6 (4.4) 0,6
Oil pipe 12 (8.8) 1,2
Oil strainer 10 (7.3) 1,0
Relief valve 64 (47.2) 6,4
Timing case 10 (7.3) 1,0
Rocker assembly nuts 33 (24.3) 3,3
Rocker cover 14 (10.3) 1,4
Electrical shut off solenoid 18 (13.2) 1,8
Sump drain plug 35 (25.8) 3,5
Temperature switch 27 (19.9) 2,7
Thermostat setscrew 14 (10.3) 1,4
