400 Series
Cylinder head assembly 3
Rocker cover and inlet manifold
To remove and to fit Operation 3-1
Notes:
l An ‘O’ ring (1) is fitted in the groove in the rocker cover.
l Inspect the ‘O’ ring and renew if necessary.
Engine Torque Nm (lbf ft) kgf m
403C-11
Cap nut 11 (8.1) 1,1
Setscrew 11 (8.1) 1,1
403C-15
404C-22
404C-22T
Cap nut 14 (10.3) 1,4
Setscrew 14 (10.3) 1,4
H1034
1
