Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 9
2
400 Series
Specifications 2
Basic engine data
Engine model 403C-11 403C-15 404C-22 404C-22T
Engine build code HH HL HP HR
Number of cylinders 3 3 4 4
Cylinder
arrangement
Vertical in line
Cycle Four stroke
Direction of rotation Clockwise from the front
Induction system Naturally aspirated Turbo charged
Combustion system Indirect injection
Nominal bore 77 mm (3.03 in) 84 mm (3.3 in)
Stroke 81 mm (3.19 in) 90 mm (3.5 in) 100 mm (3.9 in)
Compression ratio 23: 1 22.5: 1 23.3: 1
Cubic capacity 1,131 litres (69 in³) 1,496 litres (91 in³) 2,216 litres (135.2 in³)
Firing order 1, 2, 3 1, 2, 3 1, 3, 4, 2
Valve tip clearance (cold)
Inlet 0,2 mm (0.0078 in)
Exhaust 0,2 mm (0.0078 in)
Governor Mechanical all speed
Fuel injection Cassette type fuel injection pump
Electrical system 12 Volt
Lubricating oil
pressure relief valve
304 - 500 kPa 262 - 359 kPa 352 - 448 kPa
Lubricating oil
pressure switch
located on top cover
49,0 kPa 29,4 kPa
Lubricating oil
pressure switch
located on cylinder
block oil rail
49,0 kPa 98,0 kPa
