Perkins 404C-22T - Pressure Relief Valve

10
78 Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green
400 Series
Pressure relief valve
To remove and to fit Operation 10-2
Renew the ‘O’ ring (1) when the pressure relief valve is fitted to the cylinder block.
Caution: When the crankshaft is removed or fitted the pressure relief valve must be removed first.
Engine Torque Nm (lbf ft) kgf m
All models Pressure relief valve 64 (47) 6,5
H1091
1
