Perkins 404C-22T - Cylinder Block Assembly; Front Crankshaft Bush

Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 65
7
400 Series
Cylinder block assembly 7
Front crankshaft bush
To remove and to fit Operation 7-1
Caution: Ensure that the lubrication oil hole in the bush, aligns with the oil gallery in the block.
To remove the bush use a suitable drift and hammer from the inside of the block.
Use a suitable press to fit the crankshaft bush.
Note: The bush must be fitted with the chamfered side (2) towards the cylinder block, with the join (1) at the
top.
2
1
H1082/1
