Perkins 404C-22T Workshop Manual

6
Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 63
400 Series
Oil pump end float
To check and adjust Operation 6-13
Use a feeler gauge to check the oil pump end float (2).
Adjust with 0,1 - 0,15 - 0,2 and 0,5 mm shims (1).
Engine Standard clearance mm (in) Service limit
mm (in)
All models 0,10 - 0,15 (0.0040 - 0.0060) 0,20 (0.0079)
H1080
2
1
