Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 79
400 Series
Lubricating oil sump
To remove and to fit Operation 10-3
Note: When the sump is fitted renew the joint (1).
Engine Torque Nm (lbf ft) kgf m
403C-11
Sump setscrews 6 (4.4) 0,6
Sump drain plug 35 (25.8) 3,5
403C-15
404C-22
404C-22T
Sump setscrews 11 (8) 1,1
Sump drain plug 35 (25.8) 3,5
H1092
1
