11
Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 87
400 Series
Fuel lift pump
To remove and to fit Operation 11-2
The fuel inlet for the fuel lift pump can rotate 360° and is adjustable in 15° increments.
The fuel lift pump flange has two sets of locating holes this allows the pump to be fitted in four positions for the
outlet connection.
Engine Torque Nm (lbf ft) kgf m
All models
Lift pump setscrew 6 (4.4) 0,6
Lift pump inlet adjusting bolt (1) 2,5 (1.8) 0,25
H1099
1
