KENR9126 155
Troubleshooting Section
Table 33
P2/J2 Pin Connections
Function
Sensor Pin Primary Sensor Secondary Sensor
+8 Volt Supply
110 10
Signal
252 53
g01803493
Illustration 55
The schematic for the speed/timing senso rs
g01803494
Illustration 56
Pin locations on the P2 connector for the speed /timing sensors
(10) S peed/timing sensor s upply (+8 Volts
DC)
(52) P rimary speed/timing sensor signal
(53) Sec ondary speed/timing sensor signal
