permaPROC-16-
Caption for Chart on Left Side
Instructionsshouldbefollowedfromtoptobottomandfromlefttoright(alsorefertochart4).Theinstructions
correspondtotheoperatingsequenceontheturnedofflubricationsystempermaPROC.Congurationisalso
possibleifpermaPROCisOn.
chart7
Function shortpush longpush blinkingdisplay goto
Symbol
CONFIGURATION SECTIONS (see vertical bar, chart 6)
I N T R O
INTROinforms

Info
andasksforthecurrentPIN.

PINEntry
C O N F I G U R A T I O N M E N U E
Settingscanbechangedinthecongurationmenuwithitsdifferentsections(LC,Time,Outlets,PIN).
LC
YoucanchangethePROLCunitsizefromLC250toLC500andbackbypushingtheSELECTbutton(referto
chapter7.1and7.2).
Time
Thedischargeperiodcanonlybesetin one typeofcalendarunit(i.e.eitherMonths,Weeks,orDays).When
thehighestunitisreached,countingstartsagainwithnumber“
”(exceptwithdays“ ”=ImpulseMode,
refertochapter6.10).
Outlets
Theactivatedoutlets1-6aredisplayedwithalledinsquareinthedisplay(pleaserefertotheoperating
instructionoftheMP-6distributorformoredetails).Ifnodistributorisconnected,congurationofoutletshas
noeffect.
PIN
WestronglysuggesttoenterapersonalPINinordertoprotectyoursettingsfromunauthorizedaccess.The
PINcanonly be changed during initial conguration or after a PIN-reset.APIN-reset(shortpushofbut-
tons:left-left-right-right-leftintheINTRO-Info-menu)changesyourpersonalPINbackto“
”.ThePIN-reset
wassuccessfulwhenthedisplayedtimedisappearsforasecondandthencomesbackon.Allothersettings
remainunchanged.
Save or Reject Changed Settings
ThedisplaysettingscanbesavedwithalongpushoftheMODE/SAVEbutton.Ifyoudonotwanttosaveyour
changestosettingthatarecurrentlydisplayedinthecongurationmenu(LC,Time,Outlets,PIN),pressthe
SELECTbuttonuntilthedisplayshowseither(“
”)forOffortheremainingvolumeofthePROLCunitin%
VOL.Allothersettingsandalreadysavedchangesremainvalid.
Automatic Termination of the Conguration Mode
Ifyoudonotpressabuttoninthecongurationmodefor180seconds,thecontrolsystemisautomatically
switchingbacktothepreviouslysetmode(“On”or“Off”)withoutsavingthechanges.
Thesettingsexistingpriortothechangeremainvalid.
Additional Discharge
Withanadditionaldischarge,alubricationpointcanbesuppliedwithanadditionalamountofthelubricant.
Foranadditionaldischarge,thelubricationsystemmustbeswitchedon(displayshowstheremainingvolume)
andbothbuttonsmustbehelddownsimultaneously(refertogure15).
gure15 LubricatorOn Foranadditionaldischarge,pressbothbuttonsatthe
  sametimeandholdthemdown(>4sec.)
Anadditionaldischargeisonlypossibleattemperaturesabove0°C/32°F(gure16,icecrystalisnotvisible)
andwhenthelubricationsystemisnotcurrentlyconductingaregulardischarge.
Everyadditionaldischargereducestheremainingdischargeperiodsinceanincreasedamountofthelubricant
hasbeensupplied.Thismustbetakenintoaccountinyourlubricationandmaintenanceschedule.
The time between two additional discharges is at least 30 seconds. Each additional long push of
both buttons (simultaneously) (gure 15) during this time is being registered and will lead to even
more additional discharges. The system remembers a max. of 5 additional discharges.
MODE
SAVE
SELECT
%Vol.
LC 500
