Perma PRO 250 - Page 52

permaPROMP-6Distributor -1-
Accessories
Activation of Outlets on Lubrication System PRO / PRO C
The Distributor perma MP-6
MODE
SAVE
Config.
Outlets
1
3
2
4
5
6
On/OffOutlet1
PROC PRO
or
SELECT
ON/OFF
SELECT
Congurationofoutlets:
Activationofoutlet1
Config.
Outlets
1
3
2
4
5
6
Outlet1active
MODE
SAVE
Config.
Outlets
1
3
2
4
5
6
On/OffOutlet2
PROC PRO
or
SELECT
ON/OFF
SELECT
Config.
Outlets
1
3
2
4
5
6
Outlet2active
(ifdesired,remainingoutlets
canbeturnedOn/Offthe
sameway)
max.6mm
max.6mm
max.6mm
Outlets 1 to 3 with
connections for
greaselines
Housing
containsdrive
unitand
distributionsystem
Connection thread
forattachingalubricatorofthe
permaPROrange.
Outlets 4 to 6 with
connections for
greaselines
Connector
usedforplugginginthe
connectingcable.
Plug (4 pcs.)
forsealingtheoutletsthatare
notused.
Connecting cable (1 pc.)
usedforpowersupplyandfor
communication.
6 connections
(straightorangle)
forgreaselines.
Activation/selectionofoutletsisdoneontheconnectedlubricationsystemPRO/PROC.Pleaseobserve
operatinginstructions(refertochapter6.8)oftheattachedlubricationsystemsincethefollowingchartdoes
notgointodetail.Outletsmustbeactivatedbytheuserbeforeoperation(factorysetting=alloutletsinactive).
